Description of Representative Waveform Files
Gaussian Pulse
(GAUSS_P.WFM)
AWG2021 User Manual
Here we will describe the 17 representative waveform files. Some of the
waveform files were obtained by creating an equation file in the equation editor
and then compiling it to form a waveform file. Others were created in the
waveform editor. To output a waveform file, select the file in the
Made with the equation editor.
Figure D 1: Gaussian Pulse Formula and Waveform
Appendix D: Sample Waveform Library
SETUP
menu.
D 3
