EDIT Menu
Editing Waveform Data in
Timing Display
Operation ( More 1 of 3 )
3 104
Use Operation to edit the waveform data in a variety of ways.
The side menu is made up of 3 pages. To get to the next page of the menu, select
More. The following list shows the names and functions of the items in the side
menu.
Cut
Copy to Buffer
Paste from Buffer
Set...
Shift...
Invert...
Copy Line...
Exchange Line...
Logical Function...
Data Expand...
Insert Other Waveform
Shift Register Generator... Pseudo-random pulse generator
Cut, Copy, and Paste Processing Function. Use these functions cut, copy to the
buffer, and paste to any other time or point value within the waveform data area
between the vertical bar cursors. The functions for these items are the same as for
the corresponding items in waveform editor graphic display. See Pages 3 -43
through 3–46.
Setting Waveform Data. Use Set... to designate data for each data line and marker
in the editing area between the designated vertical bar cursors. The following
diagram shows the menu configuration for the Set... item.
Line
Set High
Set... Set Low
Go Back
Set Pattern
Cutting waveforms
Copying waveforms
Pasting waveforms
Setting the waveform data
Shifting waveform data
Inverting waveform data
Copying lines
Exchanging lines
Applying logical operations to lines
Expanding waveform data
Inserting other waveform data
Using shift register
Import Line Data /
Clear Pattern
1 Bit
Key Data
4 Bits
Initial Src
User defined
Initial Code
Code Config...
Out [I/O]
Cancel
O.K.
0
1
0
1
High/Low
Invert/Keep
