Rear Panel
RS-232-C
IEEE STD 488 PORT
CH-1
CH-2
MARKER 1 OUT
CH2
5V FROM 50W
27
Figure 2 4: Rear Panel Overall View
AWG2021 User Manual
Refer to Figure 2 5
CLOCK OUT MARKER 2 OUT
2V FROM 50W 5V FROM 50W
MARKER 2 OUT
5V FROM 50W
CLOCK IN
50W 2V MAX
SYNC OUT AM IN
CH2 CH1
3V FROM 50W
10kW 5V MAX
26
(22) Power Source
Connector
(23) PRINCIPAL POWER
SWITCH
(24) Fuse Holder
Note. When using the AWG2021 in Europe, you should use an IEC approved fuse. For details,
see page 1 4.
WARNING ATTENTION
!
TO AVOID ELECTRIC SHOCK, THE POWER CORD UN CIRCUIT DE TERRE COTINU EST
PROTECTIVE GROUNDING CONDUCTOR MUST
ESSENTIEL EN VUE DU FONCTIONNEMENT
BE CONNECTED TO GROUND.
SECURITAIRE DE L'APPAREIL.
FOR CONTINUED FIRE PROTECTION REPLACE FUSE ONLY NE JAMAIS METTRE L'APPAREIL EN
WITH 250V FUSE OF THE SPECIFIED TYPE AND RATING.
MARCHE LORSQUE LE CONDUCTEUR DE
NO OPERATOR SERVICEABLE COMPONENTS INSIDE.DO NOT MISE A LA TERRE EST DEBRANCHE.
REMOVE COVERS. REFER SERVICING TO QUALIFIED
PERSONNEL.
THIS INSTRUMENT MAY BE
PROTECTED BY ONE OR MORE
PATENTS OR
PATENT APPLICATIONS.
INFORMATION PROVIDED ON
REQUEST.
FUSE (250V) FUSE (250V)
VOLTAGE FREQUENCY
UL 198G (3 AG)
RANGE RANGE
1/4x1 1/4 5 x 20 mm
90-127VAC 48-440Hz
6 A FAST
90-250VAC 48-63Hz
DISCONNECT POWER CORD
BEFORE REPLACING FUSE.
SONY/TEKTRONIX CORP .,TOKYO.JAPAN
25
A power cord is connected to the power source connector.
When this switch is on, power is supplied to the standby circuit
in the power system. Press the ON/STBY button on the front
panel to supply power to the rest of the instrument.
The power supply fuse is enclosed in the fuse holder. The
same fuse is used for both 115 V and 230 V systems. A 6 A
fast blow fuse is used.
22
!
LISTED
R
5J52
ELECTRICAL &
ELECTRONIC MEAS &
TEST EQUIPMENT
R
AMPS POWER
IEC 127
!
MAX MAX
5 A (T) 4 A 300 W
ON
PRINCIPAL
POWER SWITCH
OFF
24 23
Overview
2 9
