AWG2021 User Manual
Cursor Link to...
Grid
NOTE. These settings are the same in all display formats (graphic, timing and
table).
In the following section, each of these items will be discussed in detail.
Selecting the Waveform Data Display Format. The View type... item allows you to
set the display format for the waveform data. There are three choices: graphic,
timing and table. The following diagram shows the menu configuration.
Setting (More 1 of 2)
When you open the waveform editor, Graphic display is selected as the default
option. If you want to change the display format, select Setting from the bottom
menu and then View type from the side menu, then select the desired format
(Timing or Table) from the sub-menu. Pressing the Go Back button cancels the
operation and causes the side menu to reappear. See page 3 -96 for a discussion
of timing display and page 3 -129 for a discussion of table display.
Setting Waveform Point Count. Waveform Points sets the number of points for
waveform data. The following diagram shows the menu configuration.
Setting (More 1 of 2)
The following formula is used to derive the number of points per period for the
waveform to be created:
Clock frequency
No of points +
Frequency of output waveforms
For example, for output of a 20 kHz sine wave, setting the clock frequency to
20 MHz will result in a waveform point value of 20 MHz / 20 kHz = 1000
points.
Linking the vertical bar cursors
Displaying a grid in the editing area
Graphic
Timing
View type...
Table
Go Back
Waveform Points
EDIT Menu
3 29
