Start Up
1 4
3. Remove the fuse from the fuse holder on the rear panel and check the fuse.
To remove the fuse, turn it counter-clock-wise with a screwdriver while
pushing it in. There are two types of fuses provided. Here is the fuse type
and rating.
Fuse
0.25 inch 1.25 inch (UL 198G,3AG): 6A
FAST, 250 V
5 mm 20 mm (IEC 127):5A (T), 250 V
4. Check that you have the proper electrical connections.
The AWG2021 operates at the following power supply voltage.
Line Voltage Range
Line Frequency
Maximum Power
CAUTION. Instruments are shipped with a power cord appropriate for use with
normal 115 V power systems. If the AWG2021 is to be used with 230 V power,
the power cord must be replaced with one appropriate for the power source
used. See Table 1-1, "Power Cord Identification", for the available power cord
types.
5. Connect the proper power cord from the rear-panel power connector to the
power system.
Fuse Cap Part
Fuse Part Number Number
159 0239 XX 200 2264 XX
159 0210 XX 200 2265 XX
90 V - 250 V
48 Hz - 440 Hz (90 V - 127 V)
48 Hz - 63 Hz (127 V - 250 V)
300 W
