AWG2021 User Manual
Numeric Specification Example. Turning the general purpose knob one click to the
right increases the value of the underscored digit by 1. Turning it one click to the
left decreases the value by 1. For example, if the value is 173.0 and the cursor is
under the 7, turning the general purpose knob left or right changes the value as
shown below. If the underscored value is already 1, turning the general purpose
knob left does not decrease the value any further.
173.0 173.0
183.0 163.0
193.0 .........
203.0 23.00
213.0 13.00
Turning right Turning left
When the value has already been increased to the maximum allowable value for
the parameter, turning the general purpose knob further to the right has no effect.
Similarly, when the value has already been decreased to the minimum allowable
value for the parameter, turning the general purpose knob further to the left has
no effect.
Basic Menu Operation
2 21
