Appendix A: Options and Accessories
Options
Option 02 (2 Channel
Output)
Option 03 (ECL Digital
Data Output)
AWG2021 User Manual
This chapter describes the options, and standard and optional accessories
available for the AWG2021.
The following options are available.
Option 02 (2-Channel Output)
Option 03 (ECL Digital Data Output)
Option 04 (TTL Digital Data Output)
Option 09 (FPP Board + FFT Editor/Convolution)
Option 1R (Rack Mount)
Option 1S (With WaveWriter S3FT400)
Option 95 (Certificate With Calibration Data)
Option B1 (With Service Manual)
Each of these options will be discussed in detail on the following pages.
This option adds second channel. This results in a 2-channel display for SETUP,
MODE and FG menus. Also, two additional connectors are added on the rear
panel (CH2 MARKER1 OUT and CH2 MARKER2 OUT). See "Rear Panel"
in Section 2 "Overview."
Option 03 provides the following signals at the rear–panel output connector.
NOTE. An AWG2021 cannot be equipped with Option 03, Option 04 and Option
09 together. Select either Option 03, Option 04 or Option 09.
Data Output. The data (D0–D11) fed to theAWG2021 internal D/A converter is
buffered and delivered to the output connector. At the same time that the analog
waveform is output, the digital output can be obtained. The output is differential
ECL output.
