Operating Examples
2 32
Figure 2 19: Waveform File List
4. Select O.K. from the sub-menu. The selected file will be confirmed and the
output conditions will be automatically set. Figure 2 -20 shows the SETUP
menu with the file GAUSS_P.WFM selected.
NOTE. The selected file is locked. Therefore, although changes can be made to
the waveform clock, filter, amplitude, offset and other output conditions, these
changes cannot be saved to the file.
