EDIT Menu
3 146
k
The k0–k9 can be specified; these are constants that may be used in
equations. Specifying a new value for the same k# replaces the old value
with the new one. If no constant is defined for k, this value will be automati-
cally set to 0.
=
Equals sign. = is used with k constants.
Example: k0=2*pi
Ends the line for the range or equation; inserting a return ( ) in the middle of
the line partitions it.
H Functions. Here are the functions that make up the equation.
sin(, cos(
The arguments for these trigonometric functions are in radians.
range(0,100 ms)
Example:
cos(2*pi*x)
Figure 3 101: Trigonometric Function Waveform Expressed With Variable x
