Overview
2 10
(25) CH1 AM IN Connector
(26) CH2 SYNC OUT
Connector (Option 02)
(27) CH2 MARKER 1 OUT
Connector (Option 02)
This connector is used to enter an external AM modulation
waveform to CH1. With a nominal input impedance of 10 kW,
the maximum voltage of the external signal that can be entered
is 5 V. At 1 V input, 100% modulation is possible.
The CH2 SYNC OUT connector provides a CH2 sync signal.
The output level is 1.2 V or greater with a 50 W termination.
The CH2 MARKER 1 OUT connector provides a user specified
CH2 marker 1. The output level is 2.5 V with a 50 W
termination.
