Table C 1: Test Equipment (Cont.)
Item
Digital multimeter
Function generator
Power supply (Option 03)
Performance Check/Adjust
ment disk
* Requires a TM 5000 Series Power Module Mainframe.
Performance Check/
Adjustment Files
AWG2021 User Manual
Minimum Requirements
DC volts range: 0.05 V to 5 V
Accuracy: ±0.1%
Output voltage: -5 V to 5 V
Output voltage: -2 V
Must use example listed
Table C-2 lists the waveform files on the Performance Check/Adjustment disk
(063-2171-XX) that are used in these performance tests, the AWG2021
front-panel settings that each file sets up, and the performance test that uses each
file.
NOTE. The files on the Performance Check/Adjustment disk are locked (the files
names are displayed with *), so the data in these files cannot be changed unless
the lock is opened. The file data includes not only waveform data, but also
output parameters.
When you select a file with the Waveform Sequence item, the AWG2021 output
parameters change to those specified in the file, and the waveform output
reflects waveform data in the file. After selecting a file, do not change an output
parameter with the SETUP menu unless a procedure instructs you to do so.
During the procedures, if you are unsure that the AWG2021 settings still match
the file's settings, select the waveform again using the Waveform Sequence item
on the SETUP menu.
HF_LF.WFM file on the Performance Check/Adjustment disk is used to adjust
the AWG2021 externally. On adjustment, see the AWG2021 Service Manual.
Appendix C: Performance Verification
Example
Fluke 8842A
Tektronix FG 5010 Program
*
mable Function Generator
Tektronix PS 5010 Program
*
mable Power Supply
Tektronix Part 063 2171 XX
Purpose
Used throughout the checks
to measure voltage.
Used to input the trigger
signal.
Used to check ECL digital
data output.
Used throughout the checks
to provide waveform files.
C 7
