EDIT Menu
Operation ( More 4 of 4 )
3 72
Type
Shift Scale Value
Region Shift...
Config...
Go Back
Execute
Table 3-3 lists the differences between this function and the Shift function .
Table 3 3: Differences Between the Shift Operations
Item Shift
Area Rotates the area delimited by the
cursors.
Shift amount Data point spacing
Interpolation at None
intersection
Data changed by manipulations performed from Region Shift... menu can be
restored to a prior state (for one operation only) using the Undo item on the
bottom menu. If the result of the operation was not what was intended, use the
Undo function to restore the original data. Iterating parameter modifications and
the Undo function can be a good way of finding optimal settings for the shift
parameters.
H Shift Type Selection. There are four types of specified region shifts, Right or
Left, in which a region is shifted to the right or left, and Expand or
Compress, in which the shift moves the data towards the center or away
form the center. The Type item selects the shift type.
Right or Left. Shifts the area bordered by the vertical bar cursors the amount
specified by the Shift Scale Value item to right or left. Figure 3 -53 shows
the data shown in the right figure is shifted by 1.
Right
Left
Expand
Compress
Linear
Interpolation
Quadratic
Add
Data Value
Replace
Exclude
Cursor Point
Include
Go Back
Smooth +/- Points
Region Shift
Shifts the area delimited by the
cursors to a different area.
Amounts less than the data point
spacing
Interpolation performed
