EDIT Menu
CRT Display
1
4
3 6
Figure 3 -2 shows the initial menu of the EDIT. A description for each callout
follows.
Figure 3 2: Display of the Initial Menu
(1) Catalog:Memory
(2) Free Memory
(3) Scroll Indicator
2
The display list shows the files in internal memory.
Available internal memory is indicated.
The file area of memory displayed on the screen is indicated by
an inverted display area in the scroll indicator. Up to 20 files
can be displayed on the screen. To display more files, scroll the
screen up or down by turning the general purpose knob.
3
