Appendix C: Performance Verification
Check Internal AM
Operation (Option 02 only)
Check Internal Add
Operation (Option 02 only)
C 26
Electrical
Characteristic Checked
Equipment Required
Prerequisites
1. Use test hookup and control settings from previous check.
2. Check internal AM operation:
a. Check Autostep Step 2:
H Push the AWG2021 MANUAL TRIGGER button, and check that
the step changes to Step 2 on the MODE menu.
H Check that the DMM reading is in the range from 2.375 VDC to
2.625 VDC.
b. Check Autostep Step 3:
H Push the AWG2021 MANUAL TRIGGER button, and check that
the Autostep changes to Step: 3 on the MODE menu.
H Check that the DMM reading is in the range from –2.625 V to
–2.375 V.
3. End procedure: Retain the test hookup and settings for the next check.
Electrical
Characteristic Checked
Equipment Required
Prerequisites
1. Use test hookup and control settings from previous check.
2. Check internal Add operation:
a. Check Autostep Step 4:
H Push the AWG2021 MANUAL TRIGGER button, and check that
the step changes to Step 4 on the MODE menu.
H Check that the DMM reading is in the range from 2.85 V to 3.15 V.
Arithmetic Operation, Amplitude Modulation, on page B 9.
Two 50 W coaxial cables, a function generator, and a digital
multimeter (DMM).
The AWG2021 meets the prerequisites listed on page C 5. It
also requires Option 02 (CH2 output channel) in the AWG2021.
Arithmetic Operation, Add, on page B 9.
Two 50 W coaxial cables, a function generator, and a digital
multimeter (DMM).
The AWG2021 meets the prerequisites listed on page C 5. It
also requires Option 02 (CH2 output channel) in the AWG2021.
