Tektronix AWG2021 User Manual page 444

Table B 2: Mechanical Characteristics
Characteristics
Net Weight
Standard
Size
Height
Width
Length
AWG2021 User Manual
Table B-1-2
Cycle to Cycle Jitter (CH1 Marker 1 Out)
Clock=250MS/s
StdDev Pk-Pk
20.0 ps 110.0 ps
Table B-1-3
Period Jitter (Clock Out)
Clock=250MS/s
StdDev Pk-Pk
11.0 ps 60.0 ps
Table B-1-4
Cycle to Cycle Jitter (Clock Out)
Clock=250MS/s
StdDev Pk-Pk
20.0 ps 110.0 ps
Description
9.7 kg
163mm (6.4 inches) with feet
363mm (14.3 inches) with handle
490mm (19.3 inches) with front cover
564mm (22.2 inches) with handle extended
Appendix B: Performance Characteristics
Clock=100MS/s
StdDev Pk-Pk
20.0 ps 90.0 ps
Clock=100MS/s
StdDev Pk-Pk
10.5 ps 50.0 ps
Clock=100MS/s
StdDev Pk-Pk
20.0 ps 90.0 ps
B 5
