Operating Examples
2 66
5. Press the MANUAL button.
Check the oscilloscope to see that each time you press the MANUAL
button, a set waveform is output once.
Autostep Mode. Using the following procedure, you can set the operation mode
to Autostep and use the MANUAL button to generate a trigger signal and
control step waveform output.
NOTE. When the operation mode is set to Autostep, it is not possible to change
the output parameters in the SETUP menu.
6. Select Autostep from the bottom menu.
The menu shown in Figure 2 -56 will appear.
Figure 2 56: Menu Displayed When Autostep is Selected
7. Choose Select Autostep File from the side menu.
A list of autostep files will appear.
