AWG2021 User Manual
NRZ1
Initial Src 0
Initial Code 0
Out[1/0] Invert/Keep
Source Data
Pattern Converted Code
0 00
1 01
RZ
Initial Src 0
Initial Code 0
Out[1/0] High/Low
Source Data
Pattern Converted Code
0 00
1 10
BIPHASE
Initial Src 0
Initial Code 0
Out[1/0] High/Low
Source Data
Pattern
Converted Code
0 01
1 10
Appendix F: Miscellaneous
F 11
