Appendix F: Miscellaneous
F 12
MFM
Initial Src 0
Initial Code 0
Out[1/0] Invert/Keep
Source Data
Pattern Converted Code
0 30
1 01
f/2f
Initial Src 0
Initial Code 0
Out[1/0] Invert/Keep
Source Data
Pattern Converted Code
0 10
1 11
1-7 RLL
Initial Src 0
Initial Code 0
Out[1/0] Invert/Keep
Source Data
Pattern
Converted Code
10 200
01 010
11 201
0010 200001
0001 200000
0011 010001
0000 010000
