Operating Examples
Example 4: Loading and Saving Files
Saving Files
2 68
NOTE. When the instrument is switched off, the data in the internal memory is
erased. Accordingly, it is necessary to copy any files that have been created or
edited onto a floppy disk or into the instrument's internal non-volatile memory
(NVRam).
In Example 4, you will load and save the file created in the previous operation.
LOAD menu. Used to enter files from a floppy disk or the instrument's internal
NVRam.
SAVE menu. Used to save files that have been created or changed onto a floppy
disk or the instrument's internal NVRam.
To save files into internal non-volatile memory (NVRam), perform the following
steps:
1. Press the LOAD/SAVE button in the MENU column.
2. Select Device from the bottom menu.
3. Select NVRam from the side menu.
4. Select Save from the bottom menu.
Figure 2 -58 shows the SAVE menu displayed.
