Appendix D: Sample Waveform Library
Introduction
Representative Waveform
Files
AWG2021 User Manual
The files and directories listed below are included in the route directory of the
Sample Waveform Library Disk that comes with the instrument. All files are
locked; this is indicated by an asterisk (*) before the file name.
There are 16 of these waveform files. If a waveform file (with the extender
.WFM
) has the same name as an equation file (with the extender
waveform file was derived by compiling that equation file.
Waveform Name
1. Gaussian Pulse
2. Lorentz Pulse
3. Sampling Function SIN(X)/X Pulse
4. Squared Sine Pulse
5. Double Exponential Pulse
6. Nyquist Pulse
7. Linear Frequency Sweep
8. Log Frequency Sweep
9. Amplitude Modulation
10. Frequency Modulation
11. Damped Sine Wave
12. Pulse Width Modulation
13. Pseudo Random Pulse
14. π/4 DQPSK I Axis Signal
15. π/4 DQPSK Q Axis Signal
.EQU
File Name
GAUSS_P.EQU
GAUSS_P.WFM
LORENTZ.EQU
LORENTZ.WFM
SINC.EQU
SINC.WFM
SQU_SIN.EQU
SQU_SIN.WFM
D_EXP.EQU
D_EXP.WFM
NYQUIST.EQU
NYQUIST.WFM
LIN_SWP.EQU
LIN_SWP.WFM
LOG_SWP.EQU
LOG_SWP.WFM
AM.EQU
AM.WFM
FM.EQU
FM.WFM
DMP_SIN.EQU
DMP_SIN.WFM
PWM.WFM
PRBS_15.WFM
DQPSKI.WFM
DQPSKQ.WFM
), the
Page
D 3
D 5
D 6
D 7
D 8
D 9
D 10
D 11
D 12
D 13
D 14
D 15
D 16
D 17
D 17
D 1
