Appendix A: Options and Accessories
Option 09 (FFT Editor and
Convolution Process)
Option 1R (Rack Mount)
Option 1S (WaveWriter
S3FT400)
Option 95 (Certificate With
Calibration Data)
Option B1
Power Cord Options
A 16
This option provides increased internal calculation speed and two additional
editors: an FFT editor and a convolution editor. See Section 3 for more informa-
tion on the FFT and convolution waveform editors.
The AWG2021 is shipped mounted in a 19-inch wide rack. In this configuration,
the floppy disk drive is accessed from the front panel. To change an AWG2021
into a rackmounted version, contact Tektronix for information.
For further information regarding the rack–mount adapter, see the instruction
sheet that comes with the rack–mount kit.
WaveWriter is an application program used to create waveforms for advanced
signal generating and processing instruments. Many Tektronix instruments, such
as arbitrary waveform generators and oscilloscopes with the "save-on-delta"
feature, are enhanced by this program. WaveWriter helps users configure
waveforms with a minimum of effort.
With the WaveWriter package, you can create new waveforms or edit waveforms
acquired from various instrument sources. WaveWriter gives you interactive
control of the waveform generating process.WaveWriter operates within the
Microsoft Windows TM environment.
A test result report will be provided with the AWG2005 when this option is
specified.
(service manual)
The following power cords are available with this instrument.
Table A 3: Power Cord Options
Option Description
A1 Europe, 220V/6A
A2 United Kingdom, 240V/6A
A3 Australia, 240V/6A
A4 North America, 240V/6A
A5 Switzerland, 220V/6A
Part Number
161 0104 06
161 0104 07
161 0104 05
161 0104 08
161 0167 00
