Appendix C: Performance Verification
Related Information
Equipment Required
Table C 1: Test Equipment
Item
Precision termination
Adapter
Adapter
BNC dual input (TEE) adapter Connectors: BNC
BNC cable (4 required)
Termination board (Option 03) Must use example equipment
ECL Digital Data Out Cable
(Option 03)
Test leads (Option 03)
TTL Digital Data Out Cable
(Option 04)
2 13 header (Option 04)
Probe, 10X (Option 04)
Test oscilloscope
Frequency counter
C 6
memory. For instructions on loading files, see Loading Sample Waveforms
on page 2 -28 in section 2.
Read Preparation and Conventions on page C-1. Also, if you are not familiar
with operating the AWG2021, read in section 2 before doing any of these
procedures.
The following equipment is required to check the performance of the AWG2021.
Minimum Requirements
Impedance: 50 W, 0.1%
Connectors: BNC
Connectors: BNC female to dual
banana
Connectors: SMA male to BNC
female
Impedance 50 W
Connectors: BNC
Length: 43 inches
Must use example equipment
Must use example equipment
Must use example equipment
Must use example equipment
10X probe
Bandwidth: >250 MHz
Frequency range: 10 Hz to 250 MHz
Example
Tektronix Part 011 0129 XX
Tektronix Part 103 0090 XX
Tektronix Part 015 0554 XX
Tektronix Part 103 0030 XX
Tektronix Part 012 0057 XX
Tektronix Part 671 2957 XX
Tektronix Part 012 1408 XX
(Standard accessory for
Option 03)
Tektronix Part 012 1381 XX
Tektronix Part 174 3192 XX
(Standard accessory for
Option 04)
Tektronix Part 131 3847 XX
Tektronix Part P6139A
Tektronix TDS500 Series
Digitizing Oscilloscope or
2400 Series Digitizing Oscillo
scope
Tektronix DC 5010 Program
mable Universal Counter/Tim
*
er
Purpose
Signal termination.
Signal interconnection.
Signal interconnection.
Signal interconnection.
Signal interconnection.
Used to check ECL digital
data output.
Used to check ECL digital
data output.
Used to check ECL digital
data output.
Used to check TTL digital
data output.
Used to check TTL digital
data output.
Used to check TTL digital
data output.
Checks output signals. Used
in many procedures.
Used to check clock frequen
cy.
