Lorentz Pulse
(LORENTZ.WFM)
AWG2021 User Manual
Made with the equation editor.
Figure D 2: Lorentz Pulse Formula and Waveform
Constants k0 indicates the half width (W
of the pulse.
Description When the pulse width is taken to be t
the following formula:
V(t) +
Settings Waveform points: 256
Clock frequency: 100 MHz
Output time: 2.56 ms
Appendix D: Sample Waveform Library
) for the pulse; k1 indicates the peak location
50
, the waveform can be expressed by
w50
1
2
1 ) 2 t
t w50
D 5
