Appendix E: Functional Operation Summary
Introduction
AWG2021 User Manual
This summary shows the AWG2021 functional block diagrams, explains each
block, and gives some operating precautions which are of practical value in
understanding the fundamental operating concepts of the instrument.
For convenience, some functional block diagrams show the configuration with a
second channel installed (Option 02). For blocks in which CH1 and CH2 operate
the same, only CH1 is explained.
