Supported Floppy Disk Files
AWG2021 User Manual
Table 3-20 shows a list of file name extensions denoting the type of disk files
that can be loaded to the internal memory of the AWG2021.
Table 3 20: Supported Floppy Disk Files
Extension Description
.ISF Waveform data files saved in ISF
format (Instrument Specific Format)
using the waveform save function in
the S34TDS1 Data Manager soft
ware.
.WVN Waveform data files saved using the
waveform save function in the
S37UT01 Utility software.
.WFB Waveform data files saved in binary
format on a DSA600A series instru
ment.
.WFM Waveform data files created in a
TDS series instrument
.WAV Waveform data files created in the
LeCroy EASYWAVE software.
.WDT Waveform element files created in a
Yokogawa Electric AG series arbi
trary waveform generator.
.EQA Equation files in MS DOS text format
created in a PC editor, etc.
All of these files are displayed in the Catalog menu screens for Disk in the
UTILITY menu and Device Disk in the LOAD/SAVE menu, the same as files
with other extensions. The extension for each file is shown in the Type column.
LOAD/SAVE Menu
Result of Load Operation
.ISF, .WVN, .WFB ,.WFM ,.WAV and
.WDT files are automatically con
verted into .WFM files in the
AWG2021 instrument's internal
format and then stored in internal
memory When this is done except
memory. When this is done, except
for the .WFM file, the name of the
file is retained as is, only the exten
sion changed to .WFM. In the .WFM
sion changed to .WFM. In the .WFM
file, file name and extension are as it
is.
.EQA files are automatically con
verted into .EQU files in the
AWG2021 instrument's internal
format and then stored in internal
memory. When this is done, the
name of the file is retained as is,
only the extension changed to .EQU.
When the following items are written
to the .EQA file, these items are
reflected in the .EQU file.
# COMMENT: <comment>
# WAVEFORM POINTS =
<point count>
