EDIT Menu
Saving Files and Exiting
the Editor
Convolution Waveform
Editor Menu Structure
Convolution
Waveform Editor
Menu Functions
3 190
When you select Exit/Write from the bottom menu, depending on what you have
selected in the side menu, a file name will be assigned to the calculated result and
the file will be saved to internal memory, after which the editor will close. When
you quit the editor, the initial EDIT menu will reappear.
The same procedure is used to save the file and exit from the convolution
waveform editor as for the waveform editor. See "Saving Files and Exiting the
Editor" in the section on the waveform editor.
The Convolution Waveform Editor menu has the structure shown in Fig-
ure 3 -136.
Bottom Menu
Waveform
Operation
Exit / Write
Figure 3 136: Convolution Waveform Editor Menu Structure
The following list shows the functions available for each menu item and the page
on which you can find a description of that function.
Table 3 11: Menu Functions
Menu
Waveform
Operation
Exit/Write
Side Menu
Waveform 1
Waveform 2
Func type
Math type
Execute
Function
Selecting a waveform file
Executing convolution/correlation
Saving files and exiting the editor
Convolution
Correlation
None
Differential
Page
3 192
3 193
3 20, 3 190
