AWG2021 User Manual
Append 0
Expand
Expand with Clock
Cancel
Leave as it is
Select the appropriate command from the side menu and change the waveform
point size.
If the data point count is set longer than the current waveform data, new points
with a value of zero are added at the right end of the waveform. On the other
hand, if the data point count is set shorter than the current waveform data, points
are deleted from the right end.
To set the waveform point value to 512:
1. Select Setting from the bottom menu.
2. Select Waveform Points from the side menu.
3. Use the numeric keys or the general purpose knob to enter a value of 512.
In the case of the numeric keys, press 5, 1, 2 and ENTER in that order.
Setting Horizontal Axis Units. Horiz. Unit sets the units for the horizontal axis for
the displayed waveform in either time or number of points. The following
diagram shows the menu configuration.
Setting (More 1 of 2)
Each time the Horiz. Unit button in the side menu is pressed, the units toggle
between Time and Point. When Time is selected, the Clock item is added to the
side menu and the clock frequency can be set.
"0" (7FF) values will be added after the data until a
size of a multiple of 8 is reached.
The data will be interpolated and expanded to make
it a multiple of 8.
The data will be interpolated and expanded to make
it a multiple of 8, and the clock speed will increase
proportionately.
The operation will be canceled and the editor screen
will reappear.
The operation will be canceled and the data will be
written as is. The file that has been created cannot be
output on this instrument.
Point
Horiz. Unit
Time
EDIT Menu
3 31
