Table C 2: File List for Performance Check/Adjustment Disk (Cont.)
No. No. File Name File Name
7 GAIN_OFF.AST
Step: 1 GAIN 1.WFM
Step: 2 GAIN 2.WFM
Step: 3 GAIN 3.WFM
Step: 4 GAIN 4.WFM
Step: 5
OFFSET 1.WFM
Step: 6
OFFSET 2.WFM
Step: 7
OFFSET 3.WFM
8 PULSE.WFM
9 SYNC_MKR.WFM
10 TRG_IN.WFM
11 EXT_CLK.WFM
12 DIGI_OUT.WFM
AWG2021 User Manual
EDIT Menu
Wfm Wfm
Shape Point
1000
1000
1000
1000
1000
1000
1000
64
200
1000
Î Î Î Î
Î Î Î Î
1000
Î Î Î Î
Î Î Î Î
4096
SETUP Menu
Clock Operation Filter
1 MHz Normal Through
1 MHz Normal Through
1 MHz Normal Through
1 MHz Normal Through
1 MHz Normal Through
1 MHz Normal Through
1 MHz Normal Through
250 MHz Through
1 MHz Through
100 MHz Through
External Through
Clock
1 MHz Normal Through
Appendix C: Performance Verification
Amp Offset
0.5 V 0 V
0.5 V 0 V
5.0 V 0 V
5.0 V 0 V
0.05 V 2.5 V
0.05 V 0 V
0.05 V -2.5 V
0.5 V 0 V
1 V 0 V
1 V 0 V
1 V 0 V
1 V 0 V
Usage Usage
Gain
Accuracy
Offset
Accuracy
Pulse
Response
SYNC Out and
MARKER OUT
Amplitude
External Trigger
Level Accuracy
External Clock
In
ECL and TTL
DIGITAL DATA
OUT Check
(Option 03 and
04)
