Saving Files and Exiting
the Editor
FFT Editor Menu Structure
Bottom Menu
Select
FFT Editor
Window
AWG2021 User Manual
Select Exit/Write from the bottom menu. Then select from the side menu to
save the edited file to the internal memory of the AWG2021 and exit from the
editor. When this is done, the frequency domain data is converted into time
domain data and saved as a waveform file.
The same procedure is used to save the file and exit from the FFT editor as for
the waveform editor. See "Saving Files and Exiting the Editor" in the section on
the waveform editor.
The FFT Editor menu has the structure shown in Figure 3 -142.
Rectangle
Hanning
Hamming O.K.
Blackman
Harris
Cancel
Blackman
Triangle
Figure 3 142: FFT Editor Menu Structure
Bottom Menu Side Menu
Right peak
Left peak
Operation
Draw...
Zoom
Low Pass
High Pass
Filter
Band Pass
Band Elim
Apply filter
Cut under
Delete Even
Limiter
Delete Odd
Shift Mag
Undo
Write and Exit
Exit/Write Exit without Writing
Write
EDIT Menu
