EDIT Menu
3 160
time domain with the syntactical error. Correct the error as instructed by the
message, and then compile again.
The compiled waveform file contains the settings for the number of waveform
points (set with Setting) and the clock frequency (obtained from the total time set
with the range item.) Other output parameters are set to the default values.
The compiled waveform also has a vertical axis on which –1.0 is data value 0
and +1.0 is data value 4094. There is no relation between these values and the
actual output voltage.
