Appendix B: Performance Characteristics
Table B 1: Electrical Characteristics (Cont.)
Characteristics
AM
Range
Impedance
Clock
Impedance
Function Generator
Waveform Shape
Output Parameter
Frequency
Amplitude
Offset
Polarity
Duty
Operating Mode
Auxiliary Output
Marker Signal
Display
CRT
Display Area
Resolution
AC Power Source
AC Line Power
Fuse Rating
Battery
Type
B 4
Description
2 V (-1V  1V) for 100% modulation
p p
10 kW
50 W
Sine, Triangle, Square, Ramp, Pulse
All of these values with the exception of frequency can be set independently for
each channel. Frequency settings apply to each channel.
1.000 Hz to 2.500 MHz
Can be set between 50 mV and 5 V in 1 mV increments
Can be set between 2.5 V in 5 mV increments
Normal, Invert
0% to 100% Pulse only. Can be set in 1% increments
Continuous mode
2.5 V into 50 W, generated at the starting point of the waveform. The pulse
width will vary depending on the frequency.
132mm(5.2 inches) horizontally by 99mm( 3.9 inches) vertically
640 (H) 480 (V) pixels
6A fast blow, 250 V, UL198G(3AG) or 5 A (T), 250 V, IEC127
Li3 V, 650 mAH
Table B-1-1
Period Jitter (CH1 Marker 1 Out)
Clock=250MS/s
StdDev Pk-Pk
11.0 ps 60.0 ps
Clock=100MS/s
StdDev Pk-Pk
10.5 ps 50.0 ps
