EDIT Menu
Settings for the Waveform
to be Edited
3 28
(3) D
(4) Horizontal Scroll
Indicator
(5) R
Value
(6) No. of Waveform Points
(7) Top Waveform Level
(8) Vertical Scroll Indicator
(9) Bottom Waveform Level
(10) Marker
(11) Left Vertical Bar Cursor
(12) Right Vertical Bar
Cursor
(13) Button Operations
Before waveform data is created, you must use the Setting item in the side menu
to select the environment for editing. The following settings are available:
View type...
Waveform Points
Horiz. Unit
Clock
Shows the time or point count between the left and right
vertical bar cursors.
When the display is magnified horizontally with Zoom, this
indicator is displayed to show where waveform point positions
are in the CRT display area. The area displayed on the CRT is
shown with inverted display.
Shows the right vertical bar cursor position time or point value
(R) and the vertical level (Value).
Shows the number of points in the waveform being edited.
Shows the top level for the waveform data displayed on the
CRT.
When the display is magnified vertically with Zoom, this
indicator is displayed to show where the CRT display area is in
terms of the vertical axis full scale. The area displayed on the
CRT is shown with inverted display.
Shows the bottom level for the waveform data displayed on the
CRT.
Shows the timing for the marker signals 1 and 2. The number
to the right of the word MARKER" indicates the state value for
the marker at which the active vertical bar cursor (the one
displayed with a solid line) locates.
The active cursor is displayed with solid lines and the
non movable is displayed with broken lines. The left cursor
indicates the left starting point for editing.
Indicates the right end point for editing.
This area shows how the front panel buttons operate in this
menu.
Press the CURSOR button to toggle the active vertical bar
cursor between left and right.
The vertical bar cursor can be moved by pressing the
CURSOR button.
Selecting the waveform data display format
Setting waveform point count
Setting horizontal axis units
Setting clock frequency
