Tektronix AWG2021 User Manual page 217

EDIT Menu
3 98
Bottom Menu
Zoom
Setting
Undo
Standard
Waveform
Close/Write
*1 This item appears when two or more waveforms are being edited simultaneously with Another
Waveform in the side menu (under Select/Open in the bottom menu).
*2 These items appear when the displayed waveform data has been zoomed in the horizontal direction
with Horizontal Zoom in in the side menu (under Zoom in the bottom menu).
*3 This item appears when Time has been selected for Horiz. Unit in the side menu (under Setting in the
bottom menu).
*4 These items appear when Count Up or Count Down has been selected for Pattern in the side menu
(under Standard Waveform in the bottom menu).
Figure 3 76: Waveform Editor Timing Display Menu Structure (Cont.)
Side Menu
Horizontal Zoom in
*2
Horizontal Zoom out
*2
Horizontal Zoom fit
*2
Horizontal Pan
Waveform Points
View type...
Horiz.Unit
*3
Clock
*1
Cursor Link to...
Grid
Pattern
Step
*4
Max
*4
Min
Write and Close
Close without Writing
Write
Sub Menu
Graphic
Timing
Table
Waveformx
Waveformxx
Link Off
AWG2021 User Manual
