AWG2021 User Manual
NOTE. Copying will include the point at which the cursor is located. The value
indicated by D at the top of the waveform area indicates the number of points
between the two cursors, so the number of points that will be copied will be this
value plus one point (the point at which the cursor is located).
Figure 3 62: Setting the Copy Source
Setting the Destination for Waveform Copying
7. Select Waveform2 from the side menu to designate this area as the
destination for copying (the area to which the waveform will be copied).
8. Press the CURSOR button on the front panel.
9. Using the numeric keys or the general purpose knob, move the vertical bar
cursors to set the area within which the waveform will be copied. In this
example, we will set the left cursor to point 0 and the right cursor to point
999.
EDIT Menu
3 81
