Operating Examples
2 64
Figure 2 53: Setting the Marker Default
Triggered Mode. In the following steps, set the operation mode to Triggered and
generate the trigger signal with the TRIGGER MANUAL button to control the
waveform output.
4. Select Triggered from the bottom menu.
When you select this item, the side menu lists external trigger parameters
which allow you to set them. Figure 2 -54 shows the menu set for Triggered
mode.
High at the point 0
