Function Waveform Generator Mode
Function Generator Menu Structure
MENU Button
F.G
3 296
The descriptions in this section are for an instrument with Option 02, CH2
output installed. Instruments without Option 02 have only the CH1 display.
Figure 3 -199 shows the configuration of the menus in FG mode:
Bottom Menu
Channel
Sine
Triangle
Square
Ramp
Pulse
*1 Available when Option 02 has been installed.
Figure 3 199: FG Mode Menu Structure
Side Menu Select Item
Frequency
Amplitude
Offset
Polarity
Frequency
Amplitude
Offset
Polarity
Frequency
Amplitude
Offset
Polarity
Frequency
Amplitude
Offset
Polarity
Frequency
Amplitude
Offset
Polarity
Duty
CH1
*1
CH2
Normal
Invert
Normal
Invert
Normal
Invert
Normal
Invert
Normal
Invert
