Tektronix AWG2021 User Manual page 292

Autostep Editor Menu
Structure
Autostep Editor
*
* 1) Select Operation
from the bottom menu.
2) Select the icon on the
screen.
3) Press the VALUE button.
AWG2021 User Manual
The Autostep Editor menu has the structure shown in Figure 3 -125.
Bottom Menu
Operation
Jump
Undo
Exit/Write
Figure 3 125: Autostep Editor Menu Structure
Side Menu
Cut Step
Copy Step
Paste Step
Insert New Step
Append New Step
Insert Current SETUP
Swap Channel Contents...
Step No.
To First Step
To Last Step
Write and Exit
Exit without Writing
Write
Internal Clock
External Clock
Default Value
Normal
Add
AM
Ext AM
Show Catalog Entry
Clear
Set Without Parameter
Set
Through
50 MHz
20 MHz
5 MHz
1 MHz
Amplitude
Default Value
Offset
Default Value
EDIT Menu
3 173
