Overview
2 12
(30) CLOCK OUT
Connector
(31) CH1 MARKER 2 OUT
Connector
(32) CH2 MARKER 2 OUT
Connector (Option 02)
(33) CLOCK IN Connector
(34) CH1/CH2 DIGITAL
DATA OUT Connector
(Option 04)
(35) CH1 DIGITAL DATA
OUT Connector (Option 03)
This connector is used for internal clock output. The output
level is 1 V with a 50 W termination.
The CH1 MARKER 2 OUT connector provides a user specified
CH1 marker 2. The output level is 2.5 V with a 50 W
termination.
The CH2 MARKER 2 OUT connector provides a user specified
CH2 marker 2. The output level is 2.5 V with a 50 W
termination.
This connector is used for external clock input. This connector
allows external clock signals with a maximum input voltage of
2 V into a nominal 50 W input impedance.
These connectors are used to output CH1/CH2 digital data.
The output impedance will be at the TTL level at 50 W with no
termination. For details, see Appendix A Option 04."
This connector provides digital data differential ECL output. It
is mounted in the fourth slot from the top. For details, see
Appendix A Option 03."
