SETUP Menu
SETUP Menu Structure
MENU Button
SETUP
3 212
Figure 3 -152 shows the configuration of the SETUP menu.
Bottom Menu
Clock
Waveform
Sequence
CH1 Operation
Filter
Amplitude
Offset
Display
*1 Available when Option 02 has been installed.
*2 For instruments with Option 02 installed (CH2), these items switch between CH1 and CH2.
Figure 3 152: SETUP Menu Structure
Side Menu
Internal Clock
Source
*1
Divider
*2
Channel Selection
Normal
*1
AM
*1
Add
External AM
*2
Channel Selection
*2
Channel Selection
*1
Track
*2
Channel Selection
*1
Track
Select/Set Item
CH1 Clock
Frequency Setting
Internal
External
CH2 Clock
Frequency Setting
File Setting
Through
50 MHz
20 MHz
5 MHz
1 MHz
Amplitude Setting
Off
CH1
Offset Setting
Off
CH1
Graphics
Text
