EDIT Menu
Timing Display
3 96
To show the timing display for the waveform editor using the View type.... item
in the Setting menu follow this procedure.
1. Select Setting from the bottom menu.
2. Select View type... from the side menu.
Three items will be displayed in the sub-menu: Graphic, Timing and Table.
3. Select Timing from the sub-menu.
The timing display of the waveform editor will appear. See Figure 3 -75.
Figure 3 75: Timing Display
4. Select Go Back from the sub-menu. The system moves to the previous
Setting side menu.
