EDIT Menu
Saving Files and Exiting
the Editor
Equation Editor Menu
Structure
Equation Editor
3 138
Use Exit/Write in the bottom menu to save the file to the internal memory of the
AWG2021 and exit from the editor depending on the selected side menu item.
The same procedure is used to save the file and exit from the equation editor as
for the waveform editor. See "Saving Files and Exiting the Editor" in the section
on the waveform editor.
When you compile the equation then exit the equation editor, the waveform file
and the equation file are saved in internal memory with the same name but
different extension.
NOTE. If there is already a waveform file in internal memory with the name the
compiled waveform file will be given, a message is displayed asking if you are
sure you want to overwrite the old file. Answer either Cancel or O.K.
The Equation Editor menu has the structure shown in Figure 3 -97.
Bottom Menu
Operation
Setting
Compile
*1
Undo
Exit/Write
*1 This item appears when Operation in the bottom menu has been selected.
Figure 3 97: Equation Editor Menu Structure
Side Menu
Cut Line
Copy to Buffer
Paste from Buffer
Word Table
Insert Other Equation
Waveform Points
Write and Exit
Exit without Writing
Write
