SETUP Menu
SETUP Menu Display
3 214
Figure 3 -153 shows the graphic mode for SETUP menu display. A description
for each callout follows.
1
2 2
8
Figure 3 153: SETUP Menu (Graphic Mode)
(1) Display Area for CH1
Waveform/Sequence
Waveform
(2) CH1 Clock Setting
(3) CH2 Clock Setting
(4) CH1 Operation Setting
(5) CH1 Output Parameter
Settings
(6) CH1 Output On/Off
5
3
4
Shows the waveform or sequence file waveform indicated in
the CH1 file input column. If the file is locked, an L is shown in
the upper right corner of this area.
Shows the clock source and the frequency for the internal
clock.
For instruments with Option 02 installed (CH2), shows the
internal clock frequency for CH2 and the value for frequency
division of the CH1 clock.
Shows the operation setting for the CH1 waveform.
Shows the filter applied to output, the amplitude of the output
waveform and the offset setting.
Shows whether CH1 output is on or off. To turn CH1 output on
or off, use the CH1 On/Off button on the front panel.
6
7
