Functional Description
ADSP-SC58x MLB Register List
The MediaLB Device Interface Macro 2 (MediaLB DIM 2), also referred to as OS62420, implements the required
functionality of a Media Local Bus (MediaLB) device. This logic serves as an interface between the inter-chip Medi-
aLB bus and a customer IC, implementing the physical- and link-layer requirements outlined in the MediaLB Speci-
fication.
Table 28-1: ADSP-SC58x MLB Register List
Name
MLB_ACMR0
MLB_ACMR1
MLB_ACSR0
MLB_ACSR1
MLB_ACTL
MLB_CTL0
MLB_CTL1
MLB_GCTL
MLB_HCBR0
MLB_HCBR1
MLB_HCER0
MLB_HCER1
MLB_HCMR0
MLB_HCMR1
MLB_HCTL
MLB_MADR
MLB_MCTL
MLB_MDAT0
MLB_MDAT1
MLB_MDAT2
MLB_MDAT3
MLB_MDWE0
MLB_MDWE1
MLB_MDWE2
MLB_MDWE3
MLB_MIEN
28–4
Description
Peripheral Channel Mask 0 Register
Peripheral Channel Mask 1 Register
Peripheral Channel Status 0 Register
Peripheral Channel Status 1 Register
Bus Control Register
MediaLB Control 0 Register
Control 1 Register
MLB Global Control Register
HBI Channel Busy 0 Register
HBI Channel Busy 1 Register
HBI Channel Error 0 Register
HBI Channel Error 1 Register
HBI Channel Mask 0 Register
HBI Channel Mask 1 Register
HBI Control Register
Memory Interface Address Register
Memory Interface Control Register
Memory Interface Control Data 0 Register
Memory Interface Control Data 1 Register
Memory Interface Control Data 2 Register
Memory Interface Control Data 3 Register
Memory Interface Control Data Write Enable 0 Register
Memory Interface Control Data Write Enable 1 Register
Memory Interface Control Data Write Enable 2 Register
Memory Interface Control Data Write Enable 3 Register
Interrupt Enable Register
