32-Bit Arm ® Cortex ® -M0+ MCU
HT32F50231/HT32F50241
Bits Field
[10] NSB
[9:8] WLS
[5] URRXEN
[4] URTXEN
[3] HFCEN
[2] TRSM
[1:0] MODE
Rev. 1.00
Descriptions
Number of "STOP bit"
0: One "STOP bit" is generated in the transmitted data
1: Two "STOP bit" is generated when 8-bit and 9-bit word length is selected
Word Length Select
00: 7 bits
01: 8 bits
10: 9 bits
11: Reserved
USART RX Enable
0: Disable
1: Enable
USART TX Enable
0: Disable
1: Enable
Hardware Flow Control Function Enable
0: Disable
1: Enable
Transfer Mode Selection
This bit is used to select the data transfer protocol.
0: LSB first
1: MSB first
USART Mode Selection
00: Normal operation
01: IrDA
10: RS485
11: Synchronous
