32-Bit Arm ® Cortex ® -M0+ MCU
HT32F50231/HT32F50241
ADC Trigger Control Register – ADCTCR
This register contains the ADC start conversion trigger enable bits.
Offset: 0x070
Reset value: 0x0000_0000
31
Type/Reset
23
Type/Reset
15
Type/Reset
7
Type/Reset
Bits Field
[3] TM1
[2] TM0
[1] ADEXTI
[0] ADSW
Rev. 1.00
30 29 28
22 21 20
14 13 12
6 5 4
Reserved
Descriptions
ADC Conversion BFTM or PWM Event Trigger enable control
0: Disable conversion trigger by BFTM or PWM events
1: Enable conversion trigger by BFTM or PWM events
ADC Conversion GPTM or MCTM Event Trigger enable control
0: Disable conversion trigger by GPTM or MCTM events
1: Enable conversion trigger by GPTM or MCTM events
ADC Conversion EXTI Event Trigger enable control
0: Disable conversion trigger by EXTI lines
1: Enable conversion trigger by EXTI lines
ADC Conversion Software Trigger enable control
0: Disable conversion trigger by software trigger bit
1: Enable conversion trigger by software trigger bit
176 of 486
27 26
Reserved
19 18
Reserved
11 10
Reserved
3 2
TM1 TM0 ADEXTI
RW 0 RW 0 RW
25 24
17 16
9 8
1 0
ADSW
0 RW 0
July 31, 2018
