Register Map

The following table shows the A/D Converter registers and reset values.

Table 25. A/D Converter Register Map

Register
ADCCR
ADCLST0
ADCLST1
ADCSTR
ADCDR0
ADCDR1
ADCDR2
ADCDR3
ADCDR4
ADCDR5
ADCDR6
ADCDR7
ADCTCR
ADCTSR
ADCWCR
ADCTR
ADCIER
ADCIRAW
ADCISR
ADCICLR
Rev. 1.00
Offset
0x000 ADC Conversion Control Register
0x004 ADC Conversion List Register 0
0x008 ADC Conversion List Register 1
0x020 ADC Input Sampling Time Register
0x030 ADC Conversion Data Register 0
0x034 ADC Conversion Data Register 1
0x038 ADC Conversion Data Register 2
0x03C ADC Conversion Data Register 3
0x040 ADC Conversion Data Register 4
0x044 ADC Conversion Data Register 5
0x048 ADC Conversion Data Register 6
0x04C ADC Conversion Data Register 7
0x070 ADC Trigger Control Register
0x074 ADC Trigger Source Register
0x078 ADC Watchdog Control Register
0x07C ADC Watchdog Threshold Register
0x080 ADC Interrupt Enable register
0x084 ADC Interrupt Raw Status Register
0x088 ADC Interrupt Status Register
0x08C ADC Interrupt Clear Register
169 of 486
Description Reset Value
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
0x0000_0000
