Timer Counter Reload Register – CRR
This register specifies the timer counter reload value.
Offset: 0x088
Reset value: 0x0000_FFFF
31
Type/Reset
23
Type/Reset
15
Type/Reset RW 1 RW
7
Type/Reset RW 1 RW
Bits Field
[15:0] CRV
Rev. 1.00
30 29 28
22 21 20
14 13 12
1 RW 1 RW
6 5 4
1 RW 1 RW
Descriptions
Counter Reload Value
The CRV is the reload value which is loaded into the actual counter register.
240 of 486
27 26
Reserved
19 18
Reserved
11 10
CRV
1 RW 1 RW 1 RW
3 2
CRV
1 RW 1 RW 1 RW
25 24
17 16
9 8
1 RW 1
1 0
1 RW 1
