Timer Event Generator Register – EVGR
This register contains the software event generation bits.
Offset: 0x078
Reset value: 0x0000_0000
31
Type/Reset
23
Type/Reset
15
Type/Reset
7
Type/Reset
Bits Field
[10] TEVG
[8] UEVG
[3] CH3CCG
[2] CH2CCG
Rev. 1.00
30 29 28
22 21 20
14 13 12
Reserved
6 5 4
Reserved
Descriptions
Trigger Event Generation
The trigger event TEV can be generated by setting this bit. It is cleared by hardware
automatically.
0: No action
1: TEVIF flag is set
Update Event Generation
The update event UEV can be generated by setting this bit. It is cleared by hardware
automatically.
0: No action
1: Reinitialize the counter
The counter value returns to 0 or the CRR preload value, depending on the
counter mode in which the current timer is being used. An update operation of
any related registers will also be performed. For more detail descriptions, refer
to the corresponding section.
Channel 3 Capture / Compare Generation
A Channel 3 capture / compare event can be generated by setting this bit. It is
cleared by hardware automatically.
0: No action
1: Capture / compare event is generated on channel 3
If Channel 3 is configured as an input, the counter value is captured into the
CH3CCR register and then the CH3CCIF bit is set. If Channel 3 is configured as an
output, the CH3CCIF bit is set.
Channel 2 Capture / Compare Generation
A Channel 2 capture / compare event can be generated by setting this bit. It is
cleared by hardware automatically.
0: No action
1: Capture / compare event is generated on channel 2
If Channel 2 is configured as an input, the counter value is captured into the
CH2CCR register and then the CH2CCIF bit is set. If Channel 2 is configured as an
output, the CH2CCIF bit is set.
235 of 486
27 26
Reserved
19 18
Reserved
11 10
TEVG Reserved
WO 0
3 2
CH3CCG CH2CCG CH1CCG
WO 0 WO 0 WO
25 24
17 16
9 8
UEVG
WO 0
1 0
CH0CCG
0 WO 0
