32-Bit Arm
®
Cortex
®
-M0+ MCU
HT32F50231/HT32F50241
UART Divider Latch Register – URDLR
The register is used to determine the UART clock divided ratio to generate the appropriate baud rate.
Offset:
0x024
Reset value: 0x0000_0010
31
Type/Reset
23
Type/Reset
15
Type/Reset
RW
0 RW
7
Type/Reset
RW
0 RW
Bits
Field
[15:0]
BRD
Rev. 1.00
30
29
28
22
21
20
14
13
12
0 RW
0 RW
6
5
4
0 RW
0 RW
Descriptions
Baud Rate Divider
The 16 bits define the UART clock divider ratio.
Baud Rate = CK_UART / BRD
Where the CK_UART clock is the clock connected to the UART module.
BRD = 16 ~ 65535 for UART mode
474 of 486
27
26
Reserved
19
18
Reserved
11
10
BRD
0 RW
0 RW
0 RW
3
2
BRD
1 RW
0 RW
0 RW
25
24
17
16
9
8
0 RW
0
1
0
0 RW
0
July 31, 2018
