Channel 2 Capture / Compare Register – CH2CCR
This register specifies the timer channel 2 capture / compare value.
Offset: 0x098
Reset value: 0x0000_0000
31
Type/Reset
23
Type/Reset
15
Type/Reset RW 0 RW
7
Type/Reset RW 0 RW
Bits Field
[15:0] CH2CCV
Rev. 1.00
30 29 28
22 21 20
14 13 12
0 RW 0 RW
6 5 4
0 RW 0 RW
Descriptions
Channel 2 Capture / Compare Value
- When Channel 2 is configured as an output
The CH2CCR value is compared with the counter value and the comparison result
is used to trigger the CH2OREF output signal.
- When Channel 2 is configured as an input
The CH2CCR register stores the counter value captured by the last channel 2
capture event.
243 of 486
